Page 29 2019
WHYTE Service Manual
then feed the outer cable into the chain-stay following the same path as the inner
cable.
Figure 40: Make sure the inner cable is held tight where it emerges from the chain-
stay at the opposite end, otherwise it will be pushed out. Eventually the outer ca-
ble will reach the front of the chain-stay. Then manipulate both the inner cable
and the outer cable, whilst also pushing the outer cable forwards with a lot of force
and the outer cable should also find the exit hole.
Figure 41: Push the outer cable all the way through the exit hole and finally re-
move the inner cable.
9.2 To fit a “Dropper” seat-post with internal hose.
Take care to abide by safety recommendations.
Figure 42
Figure 43 Figure 44
Figure 45
Figure 47
Figure 48 Figure 49
Figure 50
Figure 51
Figure 46
Figure 53
Figure 52
