Figure 8: Bearing Insertion & Extraction 6802-2RS-MAX
(Link or Rear of Seat Stay)
Item: Description.
1 M8 Capscrew ISO4162 55 long
2 M8 Washer ISO 7089
3 M8 Nut ISO 4032
4 BOLU-WB0025 Bearing
5 BOLU-WB0025 Bearing Tool 1
6 Mating Component (ie: Link or Seat-Stay)
7 BOLU-WB0025 Bearing Tool 2
