Page 16
2019
Figure 7: Assembly
of the Seat-stays
Item Description
1
ID 15mm, OD 24mm, Width 5mm, bearing
(BOLU-WB0025)
2 Middle shield washer (O.D. 20mm)
3 Outer shield washer (O.D. 23mm)
4 Right Seat-stay
5 Left Seat-stay
WHYTE Service Manual
