WHYTE Service Manual
Rear Suspension Nm lbs.ft
M12 Flanged Screw & Flanged Nut
16.1 (Min) - 19.9 (Max) 11.9 (Min) - 14.7 (Max)
M5 Socket-head Cap Screw (T-25
Torx®)
5.0 (Min) - 6.0 (Max) 3.7 (Min) - 4.4 (Max)
M12 x 20 long Alloy Flanged Screw
15.0 (Min) - 17.0 (Max) 10.5 (Min) - 12.5 (Max
Pivot Pin (link mount, main frame) x 61
long
15.0 (Min) - 17.0 (Max) 10.5 (Min) - 12.5 (Max
M15 x 20 long Alloy Flanged Screw
15.0 (Min) - 17.0 (Max) 10.5 (Min) - 12.5 (Max
M15 x 26 long Alloy Flanged Screw
22.0 (Min) - 26.0 (Max) 16.2 (Min) - 19.2 (Max)
M15 x 87 long Pivot Pin
9.0 (Min) - 11.0 (Max) 6.1 (Min) - 7.5 (Max)
M6 x 20 long Socket Head Capscrew
9.0 (Min) - 11.0 (Max) 6.1 (Min) - 7.5 (Max)
Rear Dropout Assemblies
M4 Countersunk Screws
4.2 (Min) - 4.6 (Max) 3.1 (Min) - 3.4 (Max)
M5 Countersunk Screws
4.8 (Min) - 5.2 (Max) 3.6 (Min) - 3.8 (Max)
M5 Grub Screw
2.2 (Min) - 2.6 (Max) 1.6 (Min) - 1.9 (Max)
Seat Post Clamp
M6 Cap Screw
12 (Min) - 14 (Max) 8.9 (Min) - 10.3 (Max)
11.0: TORQUE SETTINGS
Torque explained: If no suitable Torque Wrench is available a Torque of 5 lbf.ft can be ob-
tained by applying a force of 5lb, with a Spring Balance, to the end of a spanner, 1 Foot in
length.
IMPORTANT: For all other Torque settings, refer to the specific manufac-
turers information bundled with this manual, or alternatively, refer to the
specific manufacturers website for further information.
