Kunststoffschweißtechnik
Spare parts list Chapter 10
Basic machine WIDOS 5500
Pos. Name Piece Art.no.
37 Support 1 390141
38 Protective cap, 50 x 50 6 J0227
39 Pan head screw M 10 x 25 DIN 912 3 0912J020
40 Protective cap, round 3 J0217
--
Reduction insert OD 355 - OD 400
1 set 0708...*
--
Reduction insert OD 200 -OD 280
1 set 0308...*
--
Screw M6x30 f. OD 200-OD250
8 0912F30X
--
Screw M6x25 f. OD 280
8 0912F25X
--
A
daptor half coupling (OD 315)
8 071142
--
A
daptor half coupling / Inset (OD 450)
8 3908450
--
Screw M10x30 f. OD 450
8 7984J30X
--
Screw M10x55 f. OD 315-400
8 7984J55X
--
Screw M10x100 f. OD 450 + OD 200-280
8 7984J100X
-- Hydraulic oil 2 l HLPD35
-- Plate "pressure values" 1 SCHM5500
-- Name plate 1 SCHT5500
-- Tool bag for 10 parts 1 ZWR
-- Allan key size 3 1 ZIG03
-- Allan key size 6 1 ZIG06
-- Allan key size 10 1 ZIG10
-- Socket spanner size 27 1 ZRS27
-- Allan key with T-grip size 4 1 ZIT04
-- Allan key with T-grip size 5 1 ZIT05
-- Allan key with T-grip size 7 1 ZIT07
-- transport box 1 TKA10
*) When ordering, please give the dimension !
17.02.2014 Working instruction WIDOS 5500 Page 38/ 2 of 48
