widos 5500 - Safety Measures; Conformity; Designation of the Product; Technical Data

Kunststoffschweißtechnik
Description of Product Chapter 1
17.02.14 Working Instructions WIDOS 5500 Page 7 of 48
1.3. Safety measures
In case of wrong use, wrong operation or wrong maintenance, the machine itself or products
standing nearby can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thouroughly read and the corresponding
safety regulations must be necessarily adhered to.
1.4. Conformity
The machine corresponds in its construction to the valid recommendations of the european
community as well as to the according european standard specifications. The development,
manufacturing and mounting of the machine were made very carefully.
1.5. Designation of the Product
The product is designated by two type labels which are attached at the aggregate and at the
basic machine.
They contain the type, the serial number and the year of construction of the machine.
1.5.1 Technical Data
1.5.1.1 WIDOS 5500 General Data
Material which can be welded: PP, PEHD, PE 100
Pipe diameter range: 
outside
= 200 - 500
Box for transport machine (LxWxH):
Weight:
Box for transport insert (LxWxH):
Weight:
appr. 1390 x 1340 x 1250 mm
appr. 109 kg
appr. 1520 x 600 x 340 mm
appr. 26 kg
Weight (without boxes): 280 kg
Wire cross section: 1,5 mm²
Fuse: 16 A
Emissions - Noises exceeding 80 dB (A) may occur; during
planing it is obligatory to wear ear protection.
- When using the named pipe materials and when
welding below 260°C no toxicant damp arises.
