Kunststoffschweißtechnik
Spare parts list Chapter 10
Planer WIDOS 5500
Pos. Name Piece Order no.
1 Holder for planer 1 391401
2 Planer disc, right-hand 1 391402
3 Pan head screw M10x35 DIN 912 4 0912J035
4 Ball bearing 6028 1 LL6028
5 Chain wheel, large 3/8"x7/32" 95 Z. 1 023406
6 Flat head screw M 8x20 DIN 7991 4 7991H020
7 Three-phase geared motor 1 ADG11400
8 Pan head screw M8x40 DIN 912 4 0912H040
9 Cable 6 m EL01515
10 Screwing M25x1,5 1 EV1025
11 Drive shaft for geared motor 1 0824111
12 Feathter key A8x7x90 DIN 6885 1 6885H090
13 Feather key A8x7x18DIN 6885 1 6885H018
14 Washer 1 081414
15 Flat head screw M8x20 DIN 7991 1 7991H020
16 Disc for chain weel 1 081409
17 Flat head screw M8x16 DIN 7991 1 7991H016
18 Chain wheel, small 3/8" 15 Z. 1 391406
19 Chain 3/8" 151 pieces 1 K38153
20 Chain joint 3/8" 1 KSCH38
21 Bolt 1 210410
22 Ball bearing 6003 Z 2 L6003Z
23 Washer M16 DIN 125 5 0125P
24 Hexagon nut M16x1,5 DIN 934 1 0934Y
25 Handlebar 1 071409
26 Spherical button 1 0319C40
27 Plug connector 380 V 1 EST0416
28 Cover for planer holder 1 390404
29 Pan head screw M4x16 DIN 912 4 0912D016
30 Planer disc, left-hand 1 391403
31 Suspension holder 1 081406
32 Suspension overarm 1 390407
33 Ring nut M 16 DIN 582-C15 1 0582P
34 Pan head screw M10x45 DIN 912 2 7984J045
35 Washer M10 DIN 125 2 0125J
36 Lock nut M10 DIN 985 2 0985J
37 Knife 2 MES120
38 Spacer 2 MU120
39 Flat head screw M 3x8 DIN 965 14 0965C008TX
40 Knife 2 MES085
41 Spacer 2 MU085
42 Locking for planer complete 1 082420
-- Torx screw driver T10 1 ZT10
17.02.2014
Working instruction WIDOS 5500 Page 40 of 48
