Kunststoffschweißtechnik
Spare parts list Chapter 10
Hydraulic aggregat WIDOS 5500 man
Pos. Name Piece Order no.
46 Bearing block 1 on request
47 Pan-head screw M5x45 DIN 912 2 0912E045
48 Control knob for pressure setting 1 101022
49 Bush 1 101047
50 Set screw 1 101050
51 Plate "Pressure values" 1 SCHM4600
52 Oil dipstick 1 101021
53 Hydraulic oil 1 l HLPD35
54 Filler neck 1 101026
55 Copper ring 14x18x1.5 DIN 7603 1 D14x18
56 Cable bushing Kt21 2 EKT21
57 Leading-in for tubes size 22 2 EKT22
58 Sinter-filter 15x8 41180 2 101045
59 O-ring 16x2 2 D16x2
60 Protective mounting 1 101042
61 Pan-head screw M6x16 DIN 912 4 0912F016
17.02.2014 Working instructions WIDOS 5500 Page 43 / 2 of 48
