Kunststoffschweißtechnik
Spare parts list Chapter 10
Heating Element WIDOS 5500
Pos. Name Piece Order no.
1 Terminal box 1 071554
2 Cable 1 EL02515
3Plug 1 EST0116
4 Lifting screw M 12 DIN 580 1 0580L
5 Temperature probe PT 1000 1 H09082
6 Grip 2 07021
7 Pan-head screw M 10x60 DIN 912 4 0912J060
8 Spring washer B 10 DIN 127 4 0127J
9 Tapped bushing 4 1475045
10 Heat sink 1 on request
11 Cover for terminal box 1 071555
12 Oval-head screw M 3x6 DIN 7985 4 7985C006
13 Insulating piece 1 071556
14 Heating element (400 V) 1 H5500E
-- Heating plate new 1 HP5500E
-- Heating plate in exchange 1 HPT5500E
15 Distance piece 4 081554
16 Tapped bushing 4 081553
17 Pan-head screw M 6x45 DIN 912 4 0912F045
18 Flat-head screw M 3x8 DIN 7991 2 7991C008
19 Controller G4 with triac 1 H0908230D1
20 PTFE - joining piece 1 211505
21 Screwing 1 EV0021
22 Window, tinted 1 H09071
23 Upper and lower part of housing 1 081551
17.02.2014 Working instructions WIDOS 5500 Page 45 of 48
