Planning the Installation 222 mm (8.74") installation frame
01750058390 G ProCash 2050xe USB - Installation Guide 53
222 mm (8.74") installation frame
General information
The 222 mm (8.74") installation frame has to be used if you want to install the
ProCash 2050xe USB (4-cassette dispenser) in the specified wall cutout and
with the same floor height on both sides of the wall.
The installation frame can be either a standard installation frame or a CEN
frame (identified by the 'CEN' sticker).
The installation frame is secured to the floor at the attachment points (see
section "Drilling diagram for 222 mm (8.74") installation frame").
The device (safe) is then screwed to the installation frame.
Openings which are not used have to be closed by putting in the filling pieces.
i
For mounting material see section "Mounting sets" in the chapter
"Installation".
