Drilling diagrams Planning the Installation
72 ProCash 2050xe USB - Installation Guide 01750058390 G
Drilling diagram for height-adjustable installation
racks
i
The bottom part of the installation rack is 17 mm (0.67") smaller than
the safe all around. The top part of the installation rack is 3 mm (0.12")
smaller than the safe all around.
144 (5.67")
194 (7.65")
406 (15.98")
456 (17.95")
1
5
0
(
5
.
9
1
"
)
2
2
4
.
5
(
8
.
8
4
"
)
2
7
4
.
5
(
1
0
.
8
1
"
)
5
9
1
(
2
3
.
2
7
"
)
6
4
1
(
2
5
.
2
4
"
)
472 (18.58")
Drilling depths:
Holes for installation
frame:
at least 180 mm (7.09") with 125 mm (4.92") in
concrete.
For the hole diameter please refer to the mounting
instructions of the caulking cartridge.
Hole for tear-off
sensor:
at least 40 mm (1.57") in concrete.
Consult your alarm technician about the size of the
hole and the cartridge.
