86333220 CS20 97
Scrub Deck Linkage-Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86270830 4 NUT 5/16-18 HEX NYLOCK SS
2 86010670 4 WASHER 5/16 FLAT SS
3 86259420 4
WASHER, THRUST .51ID X 1
ODBRO
4 86347930 2 BRACKET, LINKAGE, BOTTOM
5 86348210 4 SPACER, .381D X .63OD X .50, AL
6 86228990 4 BEARING,FLNGD,.314ID X.502OD
7 86346430 1 COVER, CYL DECK, 22 IN
8 73031130 13 SCREW 6X25 -10.9-A2R (IN6RD)
9 86346320 1 FRAME, LIFT ARM
10 86277470 4 SCR, 5/16-18 X 1.5 CARRIAGE SS
11 86347680 1 BRACKET, LINKAGE, TOP
12 86347910 2 FLNG BRNG, .375 X .44, NYL
13 86010680 2 WASHER 3/8 ID X 3/4 OD NYLON
14 86278330 2 SHOULDER BOLT, 3/8OD X 3/8L SS
15 86264920 4 CABLE TIE, 7" UL/CSA
To Next Page
