36 86333220 CS20
Maintenance
Scrub Deck Actuator Removal / Replacement
FOR SAFETY: Before leaving or servicing machine, stop on a level surface. Turn off machine.
1. Support deck under pad driver so that actuator pins can be removed.
2. Remove bumper screws (2).
3. Remove front battery.
4. Pull steering shaft.
5. Disconnect actuator from wiring harness.
6. From the underside of the machine, remove lower lifting pin from actuator.
7. Remove clevis pin from actuator upper bracket.
8. Lift actuator upward and free from machine.
9. Reverse steps to install.
