Winterhalter UF-L - Page 11

General operation
9
6.3.2 Info level 1
Item
Description
(1)
On/Off button
IMPORTANT Once the machine has completed operation, drain with the self-cleaning
programme ( 10.1.1)
(2)
Info field
(3)
Machine type
(4)
Current rinse temperature
INFO The rinse temperature is lowered between rinse stages to save energy. The effective
rinse temperature is only displayed at the start of the rinse.
(5)
Current tank temperature
(6)
Machine number
(7)
Switch to Info level 2 ( 6.3.3)
(8)
Back button (including menu number)
(9)
Buttons for selecting additional programmes, priming of the dosing devices and retrieving
information
(10)
Scroll keys
Overview of buttons (9)
Addresses
 Tap the button.
 The following 2 addresses appear:
 SERVICE: Address of the service technician
 CHEMICALS: Address of the chemicals supplier (rinse aid, detergent, etc.)
INFO If no addresses appear, the authorised service technician can enter the
corresponding addresses.
Soaking programme ( 6.3.2.1)
To dissolve dried-on residues.
Prime the detergent dosing device and dosing tubes
 Keep the button pressed.
 The background of the button becomes white.
 The dosing device is activated (max. 30 seconds).
Prime the rinse aid dosing device and dosing tubes
 Keep the button pressed.
 The background of the button becomes white.
 The dosing device is activated (max. 30 seconds).
Cold water pre-wash (optional) ( 6.3.2.2)
To rinse off starch and protein deposits.
