Putting the machine back into service after a long period of disuse
34
13 Putting the machine back into service after a long period of disuse
 Open the on-site water stop cock.
 Switch on the local mains disconnector.
 Close door.
 Switch on the machine.
If the machine was in a place that was not frost-free:
After extended periods of disuse, the machine must be completely climatised (at least 24 hours at 25 °C). If
this requirement is met:
 Contact an authorised service technician to put the machine back into service.
14 Installing the machine
The installation site must be frost-resistant so that the water supply systems do not freeze.
 Install the machine horizontally with the help of a spirit level.
 Adjust the base unevenness with the help of the height-adjustable machine feet.
15 Connecting the machine
Warning
The machine and any other relevant additional devices must be connected by an electrical
company authorised by the relevant electricity supplier in relation to local standards and
regulations.
15.1 Location of the connections on the machine
Rear view
Right view
K
4 entries for hoses and cables (D 8 mm)
A
Waste water connection; drain pump installed
EZ
Mains cable (available length: approx. 2500 mm)
P
Connection for equipotential bonding system (M6x20)
DOS
6 entries for hoses and cables (D 8 mm)
W1
Main water connection
W2
Cold water pre-wash (optional)
W3
Tank filling with hot water with UF Energy (optional)

Winterhalter UF-L Specifications

General

Dimensions (W x D x H)	600 x 600 x 850 mm
Rack size	500 x 500 mm
Wash Temperature	60 °C
Rinse Temperature	82 °C
Cycle Time	90 s
Power Supply	400 V / 50 Hz / 3 Ph
Type	Undercounter Dishwasher
