Product: Latera
Version: 01
14.
1 2 3 4
10 9 8 7
6 5
Fig 2 Overview of Latera Thema
1.
Head Board
2.
Satellite Panel
3.
Full-length Siderail in folded-up position
4.
Foot Board
5.
Linen Shelf with Supervisor Panel
6.
Castor Control Lever
7.
Foot Control for Height Adjustment and Examination Position
8.
Foot Control for Lateral Tilt
9.
150 mm Castor
10.
Full-length Siderail in lowered position
NOTE For safe, easy handling, wissner-bosserhoff
®
recommends that two technicians assemble the bed.
