‘FE’: is set during manual change of coupler move-
ment parameter.
'ES': Fault by Encoder, signals out of limits
‘BE’: Electrical error during rotor angle detection,
no current is flowing (Motor not connected)
‘BM’: Mechanical error during rotor angle detec-
tion (door is stalled, or rotation direction is
wrong -> press lesrn button)
‘PS’: parameter set error
11.4.8.2 ‘F2 Belt Position’
actual position of the belt, positive- door panels
open (then it is the door panel position), negative
- coupler area
11.4.4.3 ‘F3 Log Out’
By pressing F3 the communication between door
drive and WPT is stopped and the WITTUR
Programming Tool switches off.
