WITTUR MIDI - 11.4.8 F4: Next (Main Menu)

Door Drive
MIDI / SUPRA
Operating instructions
Blatt/ sheet D823MGB.024
Datum/
date 01.03.2004
Stand/
version B-18.12.2008
Geprüft/
approved WAT/MZE
EXCELLENCE IN COMPONENTS
Änderungen vorbehalten! Subject to change without notice!
11.4.7 ‘F4’: Next (Statistic)
This menu allows you to watch values described in
the following chapters by pressing the correspon-
ding function key.
11.4.7.1 ‘F1 Energy’
This counter counts the electric energy feed to the
drive in KWh.
11.4.8 ‘F4’: Next (Main Menu)
This menu allows you to watch values described in
the following chapters by pressing the correspon-
ding function key.
11.4.8.1 ‘F1 Error List’
Errors are coded with numbers or letters. Failures
displayed first are occured last. The Error List can
be delete with the key ‘F5’ .
Possible Faults are:
'EE': EEprom writing or reading fault
'OC': Over current
'RS': Faulty reference switch
'IE': Internal software fault
'AP': Fault by positon counter, door width > 3,5m
'TS': Faulty temperature sensor
'NE':Encoder not connected
'CF': Closing force potentiometer defect
'ME': Fault by motor or encoder
'SS': Standstill fault, door is blocked
'TH': temperature of the electronic or motor too
high
F1 Energy
F2
F3
F4 F8 Back
F1 Error List
F2 Belt Position
F3 Log Out
F4 F8 Back
