Door Drive
MIDI / SUPRA
Operating instructions
Blatt/
sheet
D823MGB.023
Datum/
date
01.03.2004
Stand/
version
B-18.12.2008
Geprüft/
approved
WAT/MZE
EXCELLENCE IN COMPONENTS
Änderungen vorbehalten! Subject to change without notice!
11.4.5 ‘F2’: Coupler Movement
This menu allows you to watch/modify values
described in the following chapters by pressing the
corresponding function key.
How to enter values see in chapter 11.4.2.1
This value is stored in the EEPROM.
11.4.5.1 ‘F1 Coupler Speed’
Adjustment of the maximum speed in the coupler
area. It is the same for open and close.
11.4.5.2 ‘F2 Coupler Width’
The parameter coupler width shows the distance
which the belt is moving in close end without
moving the door panels.
If this value is changed the door is stop-
ped until the learn button is pressed!
11.4.6 ‘F3’: Statistic
This menu allows you to watch values described in
the following chapters by pressing the correspon-
ding function key.
11.4.6.1 ‘F1 Counter’
This counter shows the number of the driven door
cycles.
11.4.6.2 ‘F2 Timer’
This counter show the power-on time of the door
electronic.
11.4.6.3 ‘F3 Distance’
This counter measures the absolute movement of
the drive belt in meter, but not the coupler move-
ment. (= distance the rollers have moved)
F1 Coupler Speed
F2 Coupler Width
F3
F4 F8 Back
F1 Counter
F2 Timer
F3 Distance
F4 Next F8 Back
