Parameter Sheet
*** Above parameters any changes, please refer to actual product
****
Item Parameter
OS Linux
Language Chinese/English/Others (can be customized)
Video Compression H.264 Compression Mode
OSD Overlays information such as date time and vehicle ID
GUI
Graphical User
Interface
Can connect to external LED screen. Setup system parameters with the remote
control.
Video Input
4 channel,2 channels built-in , 2 channels expansion; 1080P AHD HD / SD / Mixed
Video Input
Video Output 1 composite video output
Preview
Support 1/2/4 channels full screen preview
Resolution Support 1080P/720P/D1/CIF, MAX:4channels 1080P
Video Quality 0-7 levels, 0 is the highest level, 7 is the lowest level.
Video Standard
PAL: 100f/s , CCIR625 line,50field;
NTSC: 120f/s, CCIR525 line,60field;
CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional;
HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional;
D1: 800Kbps ~ 3Mbps, multi levels video quality optional;
720P : 1Mbps~4Mbps, multi levels video quality optional;
1080P: multi levels video quality optional;
Video
Record
System
Record Mode
The default setting is auto recording after power on. Timed recording, alarm
trigger recording and manual recording are supported.
Audio Input 3CH ,1 channels built-in , 2 channels expansion
Audio Output 1 channel
Audio
Compression G.711a compression
Alarm Input
1CH level Alarm Input
Alarm Output 1CH level Signal Output
Communication Interface 1CH RS232 &1 channel RS485
Wireless transfer
Support Built-in 3G network, WCDMA,CDMA2000,TD-SCDMA compatible with
GPRS,EDGE; Support Built-in 4G network, TTD-LTE, FDD-LTE
Position Support Built GPS/BD Module, can make playback analysis of vehicle routing
G-Sensor Support G-sensor
Video
Storage Max support 2X256GB SD Card
