Special tools and aids 40
5 Special tools and aids
Illustration (not to scale)
Manual insert jumper plug, 18-pole Item number 33 4312 1600
In addition to the jumper for the manual insert, an adapter cable is provided for connecting the FFC sensor system
Manual insert jumper plug, 10-pole Item number 33 2628 9000
USB stick Item number 33 2492 5000
WMF 5000 S/8000 S/9000 S+ Multitool Service
Item number 33 2586 8000
used to perform the following actions: Move brewer
WMF 1500 S/5000 S Multitool Item number 33 2408 4000
used to perform the following actions: Rotate grinder, adjust brewing unit; set grinding degree.
Test tool for FFC Item number 33 4279 5000
This tool provides the ability to test the machine while it is open. If the existing FFC base is defective, the test tool can
also be used as a substitute.
Gage: Item number 33 2783 5000
The gage can be used to check the spacing distance between the angle sensor and the brewer spindle
Test tool, power supply Item number 33 4264 2000
Adapter cable set Item number 33 4264 0000
for checking the power supply
The test tool can only be used with the corresponding adapter cable set. This adapter cable set must be ordered
separately.
USB mouse, keyboard
To simplify touchscreen entry, you can insert a USB mouse or keyboard into the USB slot on the front panel.
