WMF 9000 S+ - Appendix: Technical Data; Machine Specifications

103
User Manual WMF9000S +
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 390mm
Height 744mm (with bean hopper and lock)
Depth 590mm (598mm with edge, small drip tray)
Coffee bean hopper large approx.1,150g, small approx.730g
(1
Powder hopper
(optional)
approx. 1,200g each
(2
Weight empty ca. 76kg (3grinders 1mixer, 1milk)
Water supply TW10 (DN 10at least DN 6or 3/8") hose connector with
main water supply and contaminant filter, with amesh
size of 0.2mm to 0.25mm, by customers on-site.
(3
At least 0.05MPa (0.5bar) supply pressure at 2l/min
Maximum 0.6MPa (6bar). Low pressure: min. DN6or
1/4". Maximum inlet temperature 35°C. The set of
hoses provided with the new coffee machine and/or the
new water filter must be used. Do not use the old set of
hoses.
Water quality For drinking water with carbonate hardness from
5°dKH or higher, aWMFwater filter must be fitted.
Water drain tube Hose aminimum of DN 19, minimum downward slope
of 2cm/m
Use at elevation above
sea level
< 2,000m
We reserve the right to make technical modifications.
(1
The capacity depends on the size of the coffee beans.
(2
Only with optional powder hopper. The capacity depends on the powder used.
(3
These specifications (IEC60335–2-75) for the water connection to the coffee
machine apply in EU member states. It may be necessary to also observe
additional country-specific regulations. Outside the EU countries acceptance of
the standards quoted is to be checked by the legal entity or natural person who
wishes to use the coffee machine.
