CONVECTION STEAM OVEN TECHNICAL DATA
TIP: All resistance measurements were performed with the part
disconnected from the unit and the unit at room temperature.
TIP: Resistance reading can vary ±10%.
CONVECTION STEAM OVEN
Data Point Value
Element 22 Ω, 230 VAC
Convection Fan Motor 70 Ω, 230 VAC
Room Air Fan Motor 310 Ω, 230 VAC
PTC Heater
Measured at X17-1,2
310 Ω
Water Tank Drive Motor 140 Ω
Drain Pump 88 Ω, 230 VAC
Stepper Motor
Measured at X10-1,2
88 Ω
Temperature Sensor 1090 Ω
Loudspeaker 7 Ω
Temperature Sensor 300C 255 kΩ
Evaporator Heater 40 Ω, 230 VAC
Temperature Sensor 100C
Measured at X5-6,7
110 kΩ
Door Switch
Door Open - Open
Door Closed - 0Ω
CSO Resistor 1500 Ω
Thermostat 280C 0 Ω Either Side, 12 VDC
Halogen Lighting 165 Ω, 230 VAC, 25 W
Water Valve 8.7 MΩ
Food Probe 55 kΩ
CSO (SWS #13543126)
Technical Data
TECHNICAL DATA
service.subzero.com
827703 REV B.1
93
