Wolf FGB-35 - Page 80

80
3064458_201811
Ensure that the ues can be inspected regarding their free cross-section. For this,
provide an appropriate inspection aperture in the installation room, in consultation with
your local ue gas inspector.
Connections on the ue gas side are made using female connections with gaskets.
Always position female connections against the direction of the condensate ow. Install
thebalanceduewithaslopeofatleast3°towardsthegascondensingboiler.
Use spacer brackets to secure the sections in place (see installation examples).
Connectiontobalancedue
The calculated length of the balanced ue or standard ue is comprised of the straight
pipe length and the length of the pipe bends.
Example for a 60/100 system
1)
:
Straight balanced ue pipe. length 1.5 m L = straight length + bend length
1 x 87° bend
≙ 1.5 m L = 1.5 m + 1 x 1.5 m + 2 x 1.3 m
2 x 45° bends ≙ 2 x 1.3 m L = 5.6 m
Calculatingthebalanceduelength
Note: To avoid reciprocal interference between balanced ues routed above the
roof, we recommend maintaining a minimum clearance of 2.5 m between
balanced ues.
1)
Length equivalence of the system:
60/100 80/125
87° bend 1.5 m 3 m
45° bend 1.3 m 1.5 m
Minimum shaft size for room sealed operation C93x
31.Technicalinformation,balancedue
Assumption: the installation room contains
2x inspection bends, 1x 87° bend and 1.5 m
horizontal with 87° support bend
5
7
9
11
13
15
17
90 95 100 105 110 115 120 125 130 135 140
max. Schachtlänge in [m]
Schachtquerschnitt in [mm]
FGB-28 am Schachtquerschnitt eckig bei C93x in DN 80
Anschluss DN 80/125
Anschluss DN 60/100
5
7
9
11
13
15
17
100 110 120 130 140 150 160
max. Schachtlänge in [m]
Schachtquerschnitt in [mm]
FGB-28 am Schachtquerschnitt rund bei C93x in DN 80
Anschluss DN 80/125
Anschluss DN 60/100
Max. shaft length in [m]
Shaft cross-section in [mm]
Max. shaft length in [m]
Shaft cross-section in [mm]
4
6
8
10
12
14
16
18
20
22
24
90 100 110 120 130 140 150
max. Schachtlänge in [m]
Schachtquerschnitt in [mm]
FGB-35 am Schachtquerschnitt eckig bei C93x in DN 80
Anschluss DN 80/125
Anschluss DN 60/100
4
6
8
10
12
14
16
18
20
22
105 11 0 115 120 125 130 135 140 145 15 0
max. Schachtlänge in [m]
Schachtquerschnitt in [mm]
FGB-35 am Schachtquerschnitt rund bei C93x in DN 80
Anschluss DN 80/125
Anschluss DN 60/100
Shaft cross-section in [mm] Shaft cross-section in [mm]
Max. shaft length in [m] Max. shaft length in [m]
FGB-28
FGB-35
Connection DN 80/125
Connection DN 60/100
Connection DN 80/125
Connection DN 80/125
Connection DN 80/125
Connection DN 60/100
Connection DN 60/100
Connection DN 60/100
