Notifyyourlocaluegasinspectorpriortoinstallation.
C33x
4
>20
>30
5
C93x balanced ue in
a shaft DN80
C33x balanced ue in
a shaft DN80/125
B33 open ue in
a shaft DN80
C93x balanced ue
system DN80/185
horizontal and DN80
vertical
Connectiontoaconcentricbalancedueinsideashaft(examples)DN80/125,C33x
Connectiontoaueinsideashaft,C93x
1 Gas condensing boiler
2 Adaptor DN60/100 to DN80/125
 4 BalancedueDN80/125
500 mm
1000 mm
2000 mm
5 Spacer bracket
8 Separator
(slide coupling) if required
10 Inspection bend 87° DN 80/125
11 Support bend 87° DN80/125
16 Pipe collar
22 Support rail
26 Shaft cover with
UV resistant terminal
31.Technicalinformation,balancedue
