Wolf Ranges - Gas Pressure Specifications; Wolf Burner Orifice Size Chart

RANGES && RRANGETOPS
Technical Data
6-2
GAS PRESSURE
Natural Gas Minimum
Liquid Propane Minimum
Natural Gas and Liquid Propane Maximum
Gas Supply Line Pressure
Liquid Propane Manifold Pressure, with Standard Orifice
14” WC
Natural GasManifold Pressure, with Standard Orifice
7” WC
11” WC
10” WC
5” WC
Description BTU Stamp No. Part No.
Valve, Burner 16,000
Orifice, Inner Bypass *40 800892
Orifice, Outer Bypass *88 800884
Burner, Body Assy 16,000
Orifice, Inner *34 800882
Orifice, Outer *170 800872
Burner, Charbroiler 16,000
Orifice *50 800048
Burner, Griddle 18,000
Orifice *46 800047
Burner, Oven Broil 18,000
Orifice *48 800259
French Top 15,000
Orifice *170 800060
Burner, Oven Tube 30,000
Large Oven Orifice *36 800071
Burner, Oven Tube 18,000
Small Oven Orifice *48 800073
ORIFICE CHART
Natural Gas 5” WC
Description BTU Stamp No. Part No.
Valve, Burner 16,000
Orifice, Inner Bypass *25 800055
Orifice, Outer Bypass *54 800054
Burner Body Assy 16,000
Orifice, Inner *7 800052
Orifice, Outer *109 800875
Burner, Charbroiler 16,000
Orifice *56 800050
Burner, Griddle 18,000
Orifice *55 800049
Burner, Oven Broil 18,000
Orifice *56 800057
French Top 15,000
Orifice *117 800061
Burner, Oven Tube 30,000
Large Oven Orifice *1.65 800059
Burner, Oven Tube 18,000
Small Oven Orifice *55 800058
Liquid Propane Gas 10” WC
* Standard Orifice Size Supplied with Unit
