Wolf Ranges - Page 79

RRAANNGGEESS && RRAANNGGEETTOOPPSS
Wiring Diagrams
7-23
9
REIG 4 NEUT.
6
LINE
7
GND
811
REIG 2
10
REIG 3
RR
RF
GRN
FT
REIG1
REIG2
REIG3
REIG4
REIG 1
12
BLACK (2)
FRENCH TOP
SWITCH
BURNER
SWITCH
RIGHT REAR
BURNER
SWITCH
RIGHT FRONT
BURNER
YELLOW (12) ORANGE (17) VIOLET (28)
BLACK (3)
GREEN (41)
GREEN
PLUG
BLACK (35)
BLACK
WHITE (38)
WHITE
SPARK MODULE
GROUND
BLACK (1)
RT362F/RT362F-LP
