Operation
Wireless control panel
Operation doc021820 1-3
1
Patrz rysunek 1-2. Wireless control panel functions LT70AC
Saw Head
Forward/Reverse
Blade Guide In/Out
Saw Head Up/Down
Debarker On/Off
Emergency Stop
Feed Rate Dial
Debarker In/Out
Panel Working
Status Indicator
(Green)
Diagnostic socket
Starting Key
(Air-Key)
Transmitter
Activation Button
Blade Drive Motor
START/STOP
