Setup
Initial setup of upper cutter
3
3-11 doc050624 Setup
9. When the gib lock bolts are tight, tighten the height adjusting screws until they touch bot-
tom of the indentations of the knives.
CAUTION! If the height adjusting screws are screwed too tight, the
knife will crack.
10. Repeat this procedure on all straight knives you have installed in the head.
11. Check that all knives are level with the cast iron table.
WARNING! Ensure that ALL of the gib lock bolts are very tight, and
that all of the knives are secure in the cutter head and before using the
machine! Rotate the cutter head completely to ensure it does not
impact with anything when rotating. Failure to follow this may result in
serious injury or death.
WARNING! Check that all parts and wrenches used to set the lower
knives have been removed from the machine before closing the lid of
the machine! Failure to follow this may result in serious injury or death.
Initial setup of upper cutter
WARNING! Before adjusting the upper cutter on this machine always
turn off the electrical circuit supplying power to the machine. Failure to
follow this may result in serious injury or death.
