TECHNICAL INFORMATION
6 720 641 467 (2010/01)
47
_”_\Heating season
_”_\_”_\Heating season limit K 18 °C
_”_\_”_\Delay K 4 h
_”_\_”_\Direct start limit K 10 °C
_”_\Heating, maximum operating time at
hot water demand
K 20 min.
_”_\Shut down protection, change over
hot water to heating
I/S 300 s
_”_\Compressor working area settings
_”_\_”_\Delay after temporary stop I/S 30 min.
Hot water (T3)
_”_\Extra hot water
_”_\_”_\Number of hours K 0
_”_\_”_\Stop temperature K 65 °C
_”_\Hot water peak
_”_\_”_\Interval K 0 days
_”_\_”_\Start time K 03:00
_”_\_”_\Stop temperature I/S 65.0 °C
_”_\Hot water temperature
_”_\_”_\_”_\T3 Start temperature I/S 52 °C
_”_\_”_\_”_\T8 Stop temperature I/S 59 °C
_”_\_”_\_”_\T9 Stop temperature I/S 54 °C
_”_\_”_\Additional heat only?
_”_\_”_\_”_\T3 Stop temperature I/S 56 °C
_”_\_”_\_”_\T3 Hysteresis I/S 1.0 °C
_”_\_”_\Hot water, maximum operating
time at heating demand
K 30 min.
_”_\Time control hot water K Off
_”_\Hot water additional heat
_”_\_”_\T3 Start value offset I/S 5.0 °C
_”_\_”_\T3 Hysteresis I/S 2.0 °C
Temperatures
_”_\Correct sensor I/S .0
Defrost settings
_”_\T12 - T11 settings (6-11 kW)
_”_\_”_\Time for reached temperature dif-
ference
I/S 60 s
_”_\_”_\Difference at +10 °C I/S 12 °C
_”_\_”_\Difference at 0 °C I/S C
_”_\_”_\Difference at -10 °C I/S C
_”_\T12 - T11 settings (12-17 kW)
Advanced menu Level F-value
Tab. 8
_”_\_”_\Time for reached temperature dif-
ference
I/S 60 s
_”_\_”_\Difference at +10 °C I/S C
_”_\_”_\Difference at 0 °C I/S C
_”_\_”_\Differential at -10 °C I/S C
_”_\Maximum outdoor temperature I/S 13 °C
_”_\T11 Maximum temperature I/S 20 °C
_”_\Maximum time I/S 15 min.
_”_\Delay after compressor start I/S 10 min.
_”_\Minimum time between defrosts I/S 30 min.
_”_\Compressor pressure equalisation
time
I/S 60 s
_”_\4-way valve pressure equalisation time I/S 0s
_”_\Forced defrost I/S No
_”_\Heating cable time after defrost I/S 15 min.
_”_\Fan defrost
_”_\_”_\Fan defrost interval I/S 1 ggr
_”_\_”_\Fan defrost time I/S 1.0 min.
_”_\_”_\Temperature limit I/S -5 °C
Timers
Additional heat settings
_”_\Start delay I/S 60 min.
_”_\Time control additional heat I/S Off
_”_\Additional heat options
_”_\_”_\Additional heat only? I/S No
_”_\_”_\Block additional heat? I/S No
_”_\Electric additional heat settings
_”_\_”_\Power guard
_”_\_”_\_”_\Power guard I/S Off
_”_\_”_\_”_\Supply voltage I/S 400 V
_”_\_”_\_”_\Main fuse I/S 16 A
_”_\_”_\_”_\Display/Correction of Current
transformer
I/S .0 A
_”_\_”_\_”_\Current margin I/S 0.5 A
_”_\_”_\_”_\Time from tripped power guard
to possible reconnection
I/S 60 s
_”_\_”_\Connection capacity (electric element)
_”_\_”_\_”_\State total output I/S 13.5 kW
_”_\_”_\_”_\Compressor mode, output limi-
tation
I/S 4.5/6.75 kW
_”_\_”_\_”_\Additional heat only, output
limitation
I/S 9.0/13.5 kW
Advanced menu Level F-value
Tab. 8
