15 TECHNICAL INFORMATION
15.1 FACTORY SETTINGS
The table displays the factory values (F value) of the
settings that you, as a customer, (K) can change via the
customer menus Menu and Advanced menu.
The menu points in the installation and service menus (I/
S) listed in the following table become accessible to the
installer after changing the Access level, either under
menu or under Advanced menu.
Menu Level F-value
Fast restart of heat pump? I/S No
Start up
_“_\Setting the clock
_”_\_”_\Set date I/S YY-MM-DD
_”_\_”_\Set time I/S hh:mm:ss
_”_\Connected extra sensors
_”_\_”_\T5 confirms (room temperature
sensor T5)
I/S No
_”_\Air/Water pump in operation I/S Yes
_”_\Connection capacity (electric element)
_”_\_”_\State total output I/S 13.5 kW
_”_\_”_\Compressor mode, output limita-
tion
I/S 4.5/6.75 kW
_”_\_”_\Additional heat only, output limita-
tion
I/S 9.0/13.5 kW
_”_\Manual operation? I/S No
_”_\Additional heat options
_”_\_”_\Additional heat only? I/S No
_”_\_”_\Block additional heat? I/S No
_”_\Language I/S Selected
_”_\Correct sensor I/S 0
_”_\Fan defrost interval I/S 1 ggr
_”_\Fan defrost time I/S 1.0 min.
_”_\Forced defrost I/S No
_”_\Block crankcase heater at high out-
door temperature
I/S 10.0 °C
_”_\Anti-jamming mode time I/S 02:00
_”_\Alarm buzzer signal length I/S 1 min.
_”_\T1 Set point value maximum I/S 80 °C
_”_\Display
_”_\_”_\Contrast I/S 10
_”_\_”_\Brightness I/S 10
Tab. 7
_”_\Electrical connection I/S 230V/400V
_”_\Heat pump size I/S 6-11kW/
12-17kW
Room temperature setting (T5) K 20°C
Temperature increase/decrease (T5) K =
Temperature increase/decrease settings (T5)
_”_\Limit value for V or H I/S 2°C
_”_\Change when much colder/warmer I/S 8%
_”_\Change when colder/warmer I/S 3%
Extra hot water K 0 h
Temperatures K
Advanced menu Level F-value
Temperature
_”_\Lowest outdoor temperature K 20 °C
_”_\Heating system temperature
_”_\_”_\Heat curve K V=20.0 °C
H=45.6 °C
_”_\_”_\Hysteresis
_”_\_”_\Maximum K 16 °C
_”_\_”_\Minimum K 4°C
_”_\_”_\Time factor K 10
_”_\Room sensor settings (T5)
_”_\_”_\Room temperature setting K 20 °C
_”_\_”_\Room sensor influence
_”_\_”_\_”_\Change factor K 5.0
_”_\_”_\_”_\Blocking time K 4 h
_”_\Time limited settings
_”_\_”_\Time control heating
_”_\_”_\_”_\Day and time K Off
_”_\_”_\_”_\Change in temperature K -10 °C
_”_\_”_\Holiday
_”_\_”_\_”_\Date K Off
_”_\_”_\_”_\Change in temperature K -10 °C
_”_\_”_\Remote control
_”_\_”_\_”_\Remote control K Off
_”_\_”_\_”_\Change in temperature K 0°C
_”_\External control heating K Off
Tab. 8
Menu Level F-value
Tab. 7
