TECHNICAL INFORMATION
6 720 641 467 (2010/01)
49
15.2 TECHNICAL DATA
Heat pump 6 7 9.5
Output/input at +7/35°
1)
1) Output details in accordance with EN 14511.
kW 5,43 / 1,50 7,27 / 2,20 8,36 / 2,45
Output/input at +2/35°
2)
2) Output details in accordance with EN 14511.
kW 4,56 / 1,45 6,13 / 2,16 7,14 / 2,41
COP at +7/35º 3,62 3,31 3,41
COP at +2/35º 3,15 2,83 2,96
Nominal flow rate, refrigerant l/s 0.19 0.29 0.34
Internal pressure drop, refrigerant kPa 56 7
Air flow rate m
3
/h 2200
Power consumption, fan motor A 0.44
Power supply 230V 1N~ 50Hz
Fuse rating
3)
3) Safety fuse type gL-gG or MCB type C.
AT 16 25 25
Starting current (softstart) A 23,43 30,56 32,05
Compressor Scroll
Compressor oil FV 50S
Lowest/highest outgoing heat carrier temperature °C 20/65
Refrigerant mass R-407C
4)
4) Global warming potential; GWP
100
=1526
kg 2.5 2.6 2.95
Connection, refrigerant Hose 1 inch internal thread
Defrost system Hot gas with 4-way valve
Operating temperature °C -20 – +35
5)
5) Tested at -17°C according to the European standard EN 14511-4.
Dimensions (WxDxH)
6)
6) Dimensions excl. adjustable feet; subject to adjustment plus 20 mm (minimum) - 30 mm (maximum).
mm 840 x 665 x 1223
Weight kg 140 144 152
Outer casing Zinc-plated painted sheet steel
Tab. 9 Specification
