Worcester GREENSTAR 30CDi

PRE-INSTALLATION
6 720 806 548 (2013/02)14
3.7 FLUE OPTIONS
The Greenstar CDi has the option of three horizontal RSF (60/100
telescopic, 60/100 longer telescopic and 80/125 telescopic) flue
systems and two vertical RSF (60/100 or 80/125) regular flue systems:
The systems have different maximum flue lengths for different boiler
outputs and different plume management lengths.
For every extra 1000mm of plume management after the first 500mm,
the internal 60/100 flue length must be reduced by 700mm, up to a
maximum of 4500mm of plume management.
For example on a 30CDi if the plume management effective length was
1500mm, the internal flue would be reduced to 5200mm.
This page and the page opposite shows various flue options with the
straight flue lengths required to achieve the maximum flue length.
Maximum horizontal flue lengths (L)
Boiler model 100mmØ 125mmØ
No Plume
management
+ 500mm
of plume
management
+4500mm
of plume
management
No plume
management
available
30CDi 7,900mm 5,900mm 3,100mm 18,500mm
40CDi 6,000mm 4,000mm 1,200mm 12,500mm
Table 6 Maximum horizontal flue lengths
Maximum vertical flue lengths
Boiler model 100mmØ 125mmØ
30CDi 9,400mm 18,500mm
40CDi 7,500mm 16,000mm
Table 7 Maximum vertical flue lengths
NOTICE: 60/100 Flue systems:
▶ Each 90° bend used is equivalent to 1.5 metres of
straight flue.
▶ Each 45° bend used is equivalent to 0.75 metres of
straight flue.
NOTICE: 80/125 flue systems:
▶ Each 90° bend used is equivalent to 2 metres of
straight flue.
▶ Each 45° bend used is equivalent to 1 metre of
straight flue.
Telescopic horizontal flue
Flue option 1 100mmØ 125mmØ
30CDi 570mm 600mm
40CDi 570mm 600mm
Table 8 Flue option 1
Horizontal extended flue
Flue option 2 100mmØ 125mmØ
30CDi 7,900mm 18,500mm
40CDi 6,000mm 12,500mm
Table 9 Flue option 2
Horizontal extended flue with 1x90° bends
Flue option 3 100mmØ 125mmØ
30CDi 6,400mm 16,500mm
40CDi 4,500mm 10,500mm
Table 10 Flue option 3
Horizontal extended flue with 2x90° bends
Flue option 4 100mmØ 125mmØ
30CDi 4,900mm 14,500mm
40CDi 3,000mm 8,500mm
Table 11 Flue option 4
High level horizontal extended flue
Flue option 5 100mmØ 125mmØ
30CDi 7,900mm 18,500mm
40CDi 6,000mm 12,500mm
Table 12 Flue option 5
High level horiz. extended flue with 2x90° bends
Flue option 6 100mmØ 125mmØ
30CDi 6,400mm 16,500mm
40CDi 4,500mm 10,500mm
Table 13 Flue option 6
High level horiz. extended flue with 3x90° bends
Flue option 7 100mmØ 125mmØ
30CDi 4,900mm 14,500mm
40CDi 3,000mm 8,500mm
Table 14 Flue option 7
Vertical balanced extended flue
Flue option 8 100mmØ 125mmØ
30CDi 9,400mm 18,500mm
40CDi 7,500mm 16,000mm
Table 15 Flue option 8
Vertical balanced extended flue with 2x90° bends
Flue option 9 100mmØ 125mmØ
30CDi 6,400mm 14,500mm
40CDi 4,500mm 12,000mm
Table 16 Flue option 9
Vertical balanced extended flue with 2x45° bends
Flue option 10 100mmØ 125mmØ
30CDi 7,900mm 16,500mm
40CDi 6,000mm 14,000mm
Table 17 Flue option 10
