Worcester Greenstar FS 42CDi Regular - Flue Outlet Preparation; Flue Outlets

INSTALLATION
INSTALLATION & SERVICING INSTRUCTIONS
FLUE MEASURING & CUTTING
22
FLUE MEASURING & CUTTING
8 716 115 216b (09.2008)
FLUE OUTLETS (X or Y):
1
Remove seal (B) from flue adaptor (A).
2
Cut square to mark, as shown, deburr
and clean.
3 Replace seal (B).
X
Y
Y
X
Y
A B
A
B
B
1
2
3
1
3
2
