INSTALLATION & SERVICING INSTRUCTIONS
CONVERSION
KITS
44
8 716 115 216b (09.2008)
L.P.G. CONVERSION
Change code plug:
1
Release three screws (A) to remove cover
(B).
2
Remove and dispose of the existing code
plug (C).
Replace with new conversion code plug.
N.G. code plug number:
FS 30CDi 1704
FS 42CDi 1706
L.P.G. code plug number:
FS 30CDi 1705
FS 42CDi 1707
Refit panel (B) and secure with three
screws (A).
Change gas pipe:
3
Rotate gas pipe (D) anti-clockwise, pull
upwards and remove gas pipe.
4
Replace with new conversion gas pipe
(E), push downwards and rotate clockwise
to lock into position.
Conversion label:
Replace existing label with new
conversion label.
Adjust the CO
2
level:
See “Setting the air/gas ratio” under Servicing
& Spares section.
L.P.G. CONVERSION
D
3
4
a
E
b
c
a
b
c
B
A
C
2
1
