ENCordless Circular Saw
14
COMPONENT LIST
1. SAFETY SWITCH
2. ON/OFF TRIGGER
3. SOFT GRIP HANDLE
4. HEX KEY
5. BLADE GUARD LEVER
6. BLADE GUARD
7. BASE PLATE
8. PARALLEL GUIDE
9. CUTTING MARK, 0°
10. CUTTING MARK, 45°
11. PARALLEL GUIDE CLAMPING FIXTURE
12. BEVEL ADJUSTMENT LEVER
13. DUST EXTRACTION OUTLET
14. VACUUM ADAPTER
15. FIXED UPPER BLADE GUARD
16. SPINDLE LOCK BUTTON
17. DEPTH ADJUSTMENT LEVER
18. BLADE BOLT
19. OUTER FLANGE
20. SAW BLADE*
21. INNER FLANGE
22. BATTERY PACK*
*Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WX531 WX531.X (5- designation of
machinery, representative of Saw)
WX531 WX531.X**
Voltage 20V Max***
Rated speed 6900 /min
No load speed 6900 /min
Blade size
24T TCT
Blade(WA5100)
120 mm x 1.5 mmx
9.5 mmx 24 T
60T HCS
Blade(WA8302)
115 mm x 1.2 mm x
9.5 mm x60 T
Abrasive cutting
disc (WA5048)
115 mm x 1.6 mm x
9.5 mm x60 G
Cutting
capacity
Cutting Depth
at 90°
41 mm
Cutting Depth
at 45°
29.5 mm
Bevel capacity
0-46°
Machine weight (Bare tool)
1.71 Kg
** X=1-999, A-Z, M1-M9 there are only used for
different customers, there are no safe relevant
changes between these models .
***Voltage measured without workload. Initial
battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
Category
Type Capacity
20V Battery
WA3550 1.5 Ah
WA3550.1 1.5 Ah
WA3551 2.0 Ah
WA3551.1 2.0 Ah
WA3553 4.0 Ah
20V Charger
WA3880 2.0 A
WA3760 0.4 A
WA3869 2.0 A
We recommend that you purchase your
accessories from the same store that sold you the
tool. Refer to the accessory packaging for further
details. Store personnel can assist you and offer
advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
Warning: Do not release the handle until the
saw blade come to complete stop and do
not touch saw blade while the saw blade is
running.
Intended use: The tool is intended for ripping
and cross-cutting wood and other materials in
