ENCordless Circular Saw
15
straight cutting lines, while resting firmly on
the work piece.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the battery pack See Fig. A1
Charging the battery See Fig. A2
Installing the battery pack See Fig. A3
ASSEMBLY
Mounting and Removing the
Blade
Note: Lock or loose the blade
bolt, the spindle lock button
should be pressed.
Warning: Always
remove the battery
before changing the blade!
See Fig. B
Safety switch and On/Off
trigger
Warning: To avoid
cutting injury from the
sharp blade, please don’t put
your hands around the Base
Plate.
Note: Keep the dust adapter
connected to dust collecting
device when using the tool.
See Fig. C
Rip and Cross Cutting
Note: The cutting line of
saw blade is aligned with the
cutting mark 0°.
See Fig. D1, D2
Parallel Guide See Fig. E1, E2
Adjusting the Cutting Depth See Fig. F1, F2
Adjusting the Cutting Angle
Note: The cutting line of
saw blade is aligned with the
cutting mark 45°.
See Fig. G
Pocket /Plunge See Fig. H1, H2
Sawdust Removal See Fig. I
WORKING HINTS FOR YOUR
TOOL
If your power tool becomes too hot, please run your
circular saw no load for 2-3 minutes to cool the
motor. Avoid prolonged usage at very low speeds.
Protect saw blades against impact and shock.
Cutting with extreme force can significantly
reduces the performance capability of the tool and
reduces the service life of the saw blade. Sawing
performance and cutting quality depend essentially
on the condition and the tooth count of the saw
blade. Therefore, use only sharp saw blades that are
suited for the material being cut.
Choice of blades: 24 teeth for general work, approx.
40 teeth for finer cuts, more than 40 teeth for very
fine cuts into delicate surfaces, diamond for tile,
cement board, etc.
Only use saw blades recommended.
MAINTAIN TOOLS WITH
CARE
Remove the battery before carrying out any
adjustment, servicing or maintenance.
Keep tools sharp and clean for better and safer
performance. Follow instructions for lubricating and
changing accessories. Inspect tool cords periodically
and if damaged, have repaired by authorized service
facility. Your power tool requires no additional
lubrication or maintenance. There are no user
serviceable parts in your power tool. Never use water
or chemical cleaners to clean your power tool. Wipe
clean with a dry cloth. Always store your power tool
in a dry place. Keep the motor ventilation slots clean.
Keep all working controls free of dust.
Periodically clear dust and chips from guard and base
to ensure proper performance.
FOR BATTERY TOOLS
The ambient temperature range for the use and
storage of tool and battery is 0
o
C-45
o
C.
The recommended ambient temperature range for
the charging system during charging is 0
o
C-40
o
C.
ENVIRONMENTAL
PROTECTION
Disposal
The machine, its accessories and
packaging materials should be sorted
for environmentally friendly recycling.
The plastic components are labeled for categorized
recycling.
