104 Freedom SW Owner’s Guide
Specifications
NOTE: All inverter specifications are at nominal conditions: 12 (or 24) volts DC inverting 120 volts AC, unless otherwise
specified.
Inverter Specifications Freedom SW 2012 Freedom SW 2024 Freedom SW 3012 Freedom SW 3024
Output wave form pure sine wave (true sine wave)
Output power (continuous) 2000 W (up to 30 °C) 3000 W (up to 40 °C)
Output power (5 seconds) 4000 W 6000 W
Output current 17 A 24 A
Peak output current 55 A 80 A
Output frequency 60 Hz ± 0.2 Hz 60 Hz ± 0.2 Hz
Output voltage 120 VAC 120 VAC
AC output connection/s Single Split phase in/dual out,
Dual in/dual out
Peak efficiency 90% 94% 90% 94%
No-load current draw (Inverter On) <3 ADC <1.5 ADC <3 ADC <1.5 ADC
Standby current draw (Inverter Off) <0.25 ADC <0.15 ADC <0.25 ADC <0.15 ADC
Input DC voltage range 10–16 VDC 20–32 VDC 10–16 VDC 20–32 VDC
Low battery voltage shutdown cut-off 10.5 V (selectable) 21.0 V (selectable) 10.5 V (selectable) 21.0 V (selectable)
High battery voltage shutdown cut-off 16.5 V (selectable) 33.0 V (selectable) 16.5 V (selectable) 33.0 V (selectable)
