Xantrex Freedom SW Series - Specifications; Environmental Specifications

97-0019-01-01 103
Specifications
NOTE: Specifications are subject to change without prior notice.
Physical Specifications Freedom SW 2012 Freedom SW 2024 Freedom SW 3012 Freedom SW 3024
L × W × H 387×343×197 mm (15.25×13.5×7.75 in.)
Net Weight 27.5 kg (60.5 lbs) 31.5 kg (69.4 lbs)
Environmental Specifications Freedom SW 2012 Freedom SW 2024 Freedom SW 3012 Freedom SW 3024
Nominal Ambient temperature 30 °C (86 °F) 40 °C (104 °F)
Invert mode:
• Operating range (full power)
• Load @ maximum ambient
–20 to 30 °C (–4 to 86 °F)
1700W @ 60 °C
–20 to 40 °C (–4 to 104 °F)
2600W @ 60 °C
Charge mode:
• Operating range (full power)
• Current @ maximum ambient
–4 to 104 °F
(–20 to 40 °C)
80 A @ 140 °F (60 °C)
–4 to 104 °F
(–20 to 40 °C)
40 A @ 140 °F (60 °C)
–4 to 77 °F
(–20 to 25 °C)
120 A @ 140 °F (60 °C)
–4 to 104 °F
(–20 to 40 °C)
60 A @ 140 °F (60 °C)
Storage temperature range –40 to 185 °F (–40 to 85 °C) –40 to 185 °F (–40 to 85 °C)
Humidity: Operation/Storage 95% RH, non-condensing
Altitude:
• Operating
• Non-operating
4,572 m (15,000 feet)
15,240 m (50,000 feet)
Mounting deck mount, wall mount with fans and DC/AC sides facing sideward
