Xantrex Freedom SW Series User Manual

97-0019-01-01 69
Configuring the Freedom SW using the SCP
Stack
Mode
Series Stacking: For this to
operate, one Freedom SW
must be configured to
Master and the other as
L2Master, otherwise a
system-wide fault is asserted.
Master Master,S
lave,
L2Master
Parallel Stacking: For this
to operate, one Freedom SW
must be configured to
Master and the other as
Slave, otherwise a system-
wide fault is asserted.
Master Master,S
lave,
L2Master
AC In Identifies to the system the
kind of AC input the
inverters are accepting.
SHORE1 SHORE1–
SHORE5
GEN1–
GEN5
NONE
Batte
ry
Points the system to which
battery bank is used.
Batt1 Batt1–
Batt5
a. Applies to all Freedom SW models.
Table 17 Stacking Menu Description and Values
a
Item Description Default Range
FSW Owners Guide.book Page 69 Tuesday, August 7, 2018 9:03 AM

Xantrex Freedom SW Series Specifications

General

Output Voltage	120 VAC
Output Frequency	60 Hz
AC Transfer Switch	Yes
Battery Charger	Yes
Input Voltage	12V, 24V, 48V DC
Protections	Over temperature, overload, short circuit
