1–10 975-0170-01-01
4 Dual network jacks provide connection for network-enabled devices. (The number of
connections depends on your layout. Your connections may not be the same as shown here.)
6 Chassis ground point connects the chassis of the RS3000 to your system’s chassis grounding
point.
7 & 8 DC terminals – negative (black) (7) and positive (red) (8) —shown here with DC covers on.
Table 1-3
Description of Side Panel Features
Feature Description
