Xantrex RS3000

Configuration
975-0170-01-01 3–11
Battery
The second line of the device screen indicates the status of the battery.
This line displays the volts (V); current (A) as either (+) positive amps
(indicating that the battery is charging) or (–) negative amps (indicating
the battery is discharging because you’re inverting); and battery
temperature in either
°F or °C.
AC Input1 and AC Input2
When the RS3000 has external AC input connected, these AC display
lines indicate the status of the AC input. Each AC display line shows the
values for current (A), frequency (Hz), and the AC voltage in (V).
AC Out
This line is displayed only when the RS3000 is in invert mode. This line
indicates the AC output and shows the values for
current (A), the frequency (Hz), and the AC voltage in (V).
