Xantrex SOLAR CHARGE CONTROLLER 30 User Manual

Basic Operation
Automatic Cycling Status Screen
When the LCDDisplay screen is on, it continually cycles through each of
the status screens shown below.
→ → →
Shows input PV voltage. Shows input PV current.
→ → → →
Shows generated PV energy
accumulated since last reset.
Shows battery voltage.
→ →
Return to PV voltage
screen.
Shows battery temperature.
Table 3LCD Display Automatic Cycling Status Screen
26 975-1012-01-01 Rev B
Oct 2019
