Xantrex SOLAR CHARGE CONTROLLER 30 User Manual

5 SPECIFICATIONS
NOTE: Specifications are subject to change without prior notice.
Torque Specifications for Fasteners
30A charge controller terminal screws 10.6 lb-in (1.2 N-m)
Cable Specifications for PV and Battery
PV cable #8AWG, 300V(min), -40°C–90°C
Battery cable #8AWG, 300V(min), -40°C–90°C
Specifications 30A PWM Charge Controller
Part number 709-3024-01
Nominal System voltage Auto-detect
Rated charge current 30A @ 55°C
Max PV short circuit current 30A
Max PV open circuit voltage 50VDC
Battery type Sealed(AGM) / Gel / Flooded/LFP
Battery output voltage range 8–16VDC
(8–32)VDC
Self-consumption ≤4.2mA/12V
(≤2.6mA/24V)
Temperature compensation -3.0mV/°C/2V
Charge circuit voltage drop 0.21VDC
Operating temperature range -20to55°C
Storage temperature range -30to80°C
Grounding Common-negative
IP protection IP30
Unit weight 310g
Physical dimensions 178.5×105.5×48.3mm
975-1012-01-01 Rev B
Oct 2019
35
