Remote Operation
SCPI Commands for Digital Interfaces
152 Operating Manual for XDC Series Power Supply
VOLTage Sub-Register
This shows whether the present voltage level is over or under the specified trip limit.
Table 4.16 VOLTage Sub-Register
CURRent Sub-Register
This shows whether the present current level is over or under the specified trip limit.
Table 4.17 CURRent Sub-Register
POWer Sub-Register
This shows whether the present power level is over or under the specified trip limit.
Table 4.18 POWer Sub-Register
Bit Bit Weight Bit Name Description
0 1 Over VOLtage Set if the supply’s output voltage
exceeds the over-voltage trip level,
either user-specified variable trip limit,
or the fixed trip limit.
1 2 Under VOLtage Set if the supply’s output voltage is less
than the user-specified under-voltage
trip level (variable trip limit) and the
supply is in Operation state.
Bit Bit Weight Bit Name Description
0 1 Over CURrent Set if the supply’s output current is
greater than the user-specified
over-current trip level (variable trip limit)
and the supply is in Operation state.
1 2 Under CURrent Set if the supply’s output current is less
than the user-specified under current
trip level (variable trip limit) and the
supply is in Operation state.
Bit Bit Weight Bit Name Description
0 1 Over POWer Set if the supply’s output power is
greater than the user-specified
over-power trip level (variable trip limit),
and the supply is in Operation state.
1 2 Under POWer Set if the supply’s output power is less
than the user-specified under-power trip
level (variable trip limit), and the supply
is in Operation state.
