Xantrex XDC 60-100 User Manual

SCPI Command Reference
SCPI Command Summary
Release 3.0 209
Table B.11Protection Commands
Table B.12User Lines
Table B.13Output State
Function
SCPI Command
Description Query
Set Over Temperature
Response
[:]SENSe[<channel>]:TEMPerature:PROTection:LATCh
<on-off-state>
Select if output is latched off or auto
recovers in the case of an over temperature
condition
Yes
Query Over Temperature
Protection Tripped
[:]SENSe[<channel>]:TEMPerature:PROTection:TRIPped?
Query temperature protection tripped N/A
Set AC Fail Response
[:]SENSe[<channel>]:VOLTage:AC:PROTection:LATCh
<on-off-state>
Select if output is latched off or auto
recovers in the case of an AC Fail
Yes
Query AC Fail Protection
Tripped
[:]SENSe[<channel>]:VOLTage:AC:PROTection:TRIPped?
Query AC protection circuit tripped N/A
Function
SCPI Command
Description Query
Select polarity of Auxiliary
Lines
[:]OUTPut[<channel>]:AUXiliary<A|B>:POLarity
{HIGH|LOW}
Configure the polarity of the auxiliary line Yes
Select Source of Auxiliary
Line State
[:]OUTPut[<channel>]:AUXiliary<A|B>:SOURce
<aux_line_mnemonic>
Configure the auxiliary line Yes
Query state of Auxiliary
Line
[:]OUTPut[<channel>]:AUXiliary<A|B>:STATe?
Query the state of the auxiliary line N/A
Function
SCPI Command
Description Query
Set Output State
[:]OUTPut[<channel>][:STATe] <on-off-state>
Enable/disable the power supply output. Yes
Set Output State at
Power-On
[:]OUTPut[<channel>]:PON:STATe <on-off-state>
Selects the state of the output at power-on Yes
Power-On Configuration
[:]OUTPut[<channel>]:PON:RECall
{LAST|PRESet|USER<setting_location>|SEQ<sequence_numb
er>}
Configure the supply to recall last setting,
one of the user settings, factory preset
values or to enable an auto sequence.
Yes
