204 Operating Manual for XDC Series Power Supply
SCPI Command Reference
SCPI Command Summary
Table B.7Commands for Fold Protection
Table B.8Commands for Triggering
Table B.9System Commands
Function
SCPI Command
Description Query
Set Output Fold Delay
[:]OUTPut[<channel>]:PROTection:FOLD:DELay <delay>
Set the delay time (seconds) before fold
protection is triggered.
Yes
Set Output Fold Mode
[:]OUTPut[<channel>]:PROTection:FOLD[:MODE]
{NONE|CC|CP|CV}
Select which regulation mode to fold back
(None,CV, CC, CP)
Yes
Query Fold Protection
Tripped
[:]OUTPut[<channel>]:PROTection:FOLD:TRIPped?
Query if fold protection has tripped
N/A
Function
SCPI Command
Description Query
Set Immediate Initiation of
Trigger System
[:]INITiate[<channel>][:IMMediate]
Initiate a triggered event or sequence N/A
Set Trigger Source
[:]TRIGger[<channel>][:SEQuence]:SOURce
{BUS|EXTernal|IMMediate|NONE}
Sets the trigger source for triggered
setpoints
Yes
Function
SCPI Command
Description Query
Query System Error
[:]SYSTem[<channel>]:ERRor[:NEXT]?
Returns the next error in the instrument’s
error queue
N/A
Recall Default Factory
Preset
[:]SYSTem[<channel>]:RECall:DEFault
Restore the factory preset values N/A
Select Remote Control
Source
[:]SYSTem[<channel>]:REMote:SOURce
{RS232|GPIB|AVOLtage|ACURrent|AVCurrent|MCHannel}
Select the remote control source Yes
Set RS-232 Baud Rate
[:]SYSTem[<channel>]:COMMunicate:SERial[:RECeive]:BAU
D {1200|2400|4800|9600|…}
Configure the RS-232 baud rate Yes
Set RS-232 Flow Control
[:]SYSTem[<channel>]:COMMunicate:SERial[:RECeive]:PAC
E {HARDware|XON|NONE}
Select type of flow control for RS-232 Yes
Set Multichannel Address
(6000 W only)
[:]SYSTem[<channel>]:COMMunicate:MCHannel:ADDRess
<channel>
Select the multichannel unit address Yes
Set GPIB Address
[:]SYSTem[<channel>]:COMMunicate:GPIB[:SELF]:ADDRess
<GPIB_address>
Configure GPIB address Yes
Set GPIB Power On
Service Request
[:]SYSTem[<channel>]:COMMunicate:GPIB[:SELF]:PONSrq
{ON|OFF|0|1}
Configure GPIB PON SRQ Yes
Select Range for Analog
Programming Interface
[:]SYSTem[<channel>]:COMMunicate:APRogram:LEVel
{5|10}
Select analog interface voltage levels Yes
Set Remote Control
Operation (Serial
Interface)
[:]SYSTem[<channel>]:REMote:STATe
{LOCal|REMote|RWLock}
RS-232 Only. Change remote control mode Yes
Query SCPI Version
[:]SYSTem[<channel>]:VERSion?
Returns the SCPI version to which the
instrument complies. Format is YYYY.V
N/A
