XCell ATF Series - Utility Requirements

6
XCell
TM
ATF System with C410:V3 Controller
User Guide
2. Utility Requirements
UTILITY
REQUIREMENT
COMMENTS
PRIMARY
COMPRESSED AIR
Maximum 90 psi /
6.1 bar
Oil free, dry, filtered gas, i.e., medical grade
air.
SECONDARY
PRESSURE
Typically: 35 psi /
2.4bar,
Working, regulated pressure
VACUUM SERVICE
~20” / 508 mm. Hg at
maximum flow
use a service capable of sustaining ~20”Hg
at full flow
EXHAUST
Untreated discharge or user specified
ELECTRICAL
100-240V AC, 50/60Hz
ENVIRONMENT:
0-50
°
C ; 0 – 80 % RH
Temperature; Relative Humidity
STEAM (SIP)
~30lbs/hr.
Applicable to a steamable connection
between Filtration Assembly and vessel.
CONDENSATE DRAIN
Condensate drain adequate with SIP
requirements
