XCell ATF Series User Manual

7
XCell
TM
ATF System with C410:V3 Controller
User Guide
3. Size and Weight
The size of a Filtration Assembly may vary slightly based on XCell
TM
ATF system
configuration and accessories. The C410:V3 controller dimensions are fixed.
COMPONENT
DIMENSIONS
COMMENTS
H
W
D
C410:V3
Controller
inches
PNEUMATIC BOX
17
15
8
Includes all plugs and connectors.
ELECTRIC BOX
24
20
9
Includes all plugs and connectors.
Filtration
Assembly
Fully assembled system
XCell™ ATF 4
System
24 6 6x10
Indicated dimensions are estimates for the
Filtration Assembly, as the connection to the
bioreactor, the connections to the controller
and to accessories can affect height and
effective area.
XCell™ ATF 4MC
System
44 10 8x12
XCell™ ATF 6
System
44 10 8x12
XCell™ ATF 10lgcy
System
44 14 14x20
XCell™ ATF 10
System
44 14 14x20
XCell™ ATF 6
Single-use Device
38” 12” 10”
XCell™ ATF 10
Single-use Device
38” 14” 18”
C410:V3 Controller
Estimated WEIGHT (Kg)
COMMENTS
PNEUMATIC BOX ~13
Weight of the P-Box will vary
depending on the particular ATF
System it is configured to control.
ELECTRIC BOX
~23
Filtration Assembly
XCell™ ATF 4 System ~6
Weight does not include the weight of
any liquid, filter or connection
between the Filtration Assembly and
the vessel
XCell™ ATF 4MC System ~14
XCell™ ATF 6 System ~14
XCell™ ATF 10lgcy
System
~30
XCell™ ATF 10 System ~40
XCell™ ATF 6 Single-use
Device
~ 6
Does not include the weight of liquid
and A2B connectors
XCell™ ATF 10 Single-use
Device
~ 5
Does not include the weight of liquid
and A2B connectors
