XCell ATF Series User Manual

59
XCell
TM
ATF System with C410:V3 Controller
User Guide
Appendix 1: XCell
TM
Cycle Time vs. Flow Rate
Cycle time vs. Flow rate
XCell
TM
System
PUMP VOLUME (L)
ATF4
0.4
ATF6
1.3
ATF8
2.5
ATF10 lgcy
5.1
ATF10
6.0
Cycle time (sec)
FLOW RATE (L/MIN)
4
6.0
18.8
37.5
76.5
90.0
6
4.0
12.5
25.0
51.0
60.0
8
3.0
9.4
18.8
38.3
45.0
10
2.4
7.5
15.0
30.6
36.0
12
2.0
6.3
12.5
25.5
30.0
14
1.7
5.4
10.7
21.9
25.7
16
1.5
4.7
9.4
19.1
22.5
18
1.3
4.2
8.3
17.0
20.0
20
1.2
3.8
7.5
15.3
18.0
